Description
Aorun, an ultra-bright beam fixture which combines high output, fast movements and an extensive feature package. The fixture utilises a 330W HRI light source which produces heavy mid-air effects through the special designed 169mm lens.
The fixture has an 8 & 16 facet prism on-board. These prisms can be combined for even wider effects. Additionally, the gobo wheel offers 3 animation ranges, creating unique beam effects. A softening frost completes the effect package of the Aorun.
| Physical | |
| Length | 380mm |
| Width | 280mm |
| Height (head vertical) | 529mm |
| Net Weight | 18.8 KG |
| Effects | |
| Gobo wheel | 11 fixed gobo’s, 3 animation ranges + open |
| Color wheel | 14 colors + open |
| Frost | 6° motorized |
| Prism | 8 and 16 facet (combinable) |
| Shutter | Variable 0 – 100%, random, pulse |
| Dimmer | 0 – 100% |
| Optical | |
| Source | Osram Sirius HRI 330W XL |
| Lamp life expectancy | 1500 hours |
| Beam Angle | 2.3° |
| Lens diameter | 169mm |
| Photometric | |
| Output | 380000 lx @ 10m |
| Color temperature | 7600K |
| Connections | |
| Power | Powercon in and out |
| Data | 3 and 5 pin locking XLR |
| Updates | USB |
| Control | |
| Settings | LCD display |
| Protocols | DMX512, RDM |
| Channels | 14 – 16 – 16+ |
| Updates | By USB memory stick |
| Installation | |
| Mounting | Turnable quick trigger clamps |
| Orientation | Any |
| Protection rating | IP20 |
| Safety | Attachment point |
| Movements | |
| Pan | 540° |
| Tilt | 250° |
| Electrical specification | |
| Input | 100-240 V, 50/60 Hz |
| Power consumption | 450W |
| Thermal specification | |
| Minimum ambient temperature | -5° C |
| Maximum ambient temperature | 35° C |
| Cooling | Forced air |
| Approvals | |
| CE compliant |
| Included items | |
| User Manual | |
| Power cable | |
| DMX cable |
| Ordering | |
| CLF Aorun in cardboard | 160020 |
